Steel Wire Braid Steam Hose BS5342
  • Trade Terms:
    FOB, CIF, CNF, EXW, DDU, DDP, etc.
  • Supply Ability:
    600,000m / Month.
  • Port:
    NINGBO.
  • Payment:
    T/T, L/C, PayPal, Western Union, Moneygram for offline orders.
  • Package:
    By strength PP / woven film, or by pallet / reel / customized packages etc.
  • Shipping:
    By sea, by air or by express etc.
Inquire Online
CONTACT US FOR FREE SAMPLE!
Specification

1. Application: High temperature steam, hot water tec.

2. Inner tube: EPDM rubber

3. Reinforcement: One steel wire braid reinforcement.

4. Cover: High temperature and environment resistant synthetic rubber.

5. Color and surface: Black, red, green, orange etc;

                                  Fabric or smooth surface.

6. Temperature: -40℉ ~ 350℉; -40℃ ~ 150℃


Part NoBore
Hose I.D.Braid ODMax W.P.Min. B.P.Min. Bend Radius Weight
inmminmmpsimpapsimpainmm
HQ-STEAM10-08131/2"12.7 0.9323.714511450107.1 180
HQ-STEAM10-10165/8"15.9 1.0827.414511450107.9 200
HQ-STEAM10-12193/4"19.0 1.2331.314511450109.4 240
HQ-STEAM10-16251"25.4 1.4436.5145114501011.8 300
HQ-STEAM10-20321 1/4"31.8 1.7444.1145114501015.7 400
HQ-STEAM10-24381 1/2"38.1 2.0351.5145114501019.7 500
HQ-STEAM10-32502"50.8 2.5765.2145114501025.6 650


Applications

Use in the construction, agriculture, forestry, underground or open pit mining or other industries on applications.
